Description

Overview

This switch sits at the center of a multi-way lighting circuit. If a room or hallway uses three or more switching points, the intermediate module makes it possible. The built-in LED locator glows softly in the dark, helping users spot the switch without fumbling around at night.

The Unica X design keeps things sharp and minimal. It works well in residential projects, hotel corridors, stair landings, or any spot where lighting controls need to be accessible from several positions.

Technical Specifications

• Brand: Schneider Electric

• Series: Unica X

• Function: Intermediate, with LED indicator

• Gang: 1

• Rating: 16AX / 20A

• Voltage: 250V AC

• LED Indicator: Yes (locator LED)

• Suitable Loads: LED, CFL, halogen, incandescent, inductive

• Mechanism Life: 20,000+ cycles

• Terminals: Screw-type

• Mounting: Flush

• Plate Size: 86 × 86 mm

• Material Finishes: PW, JB, SS, DG, DB, AB, AG

• Standards: IEC 60669-1

• IP Rating: IP20

Why Choose This Model?

It’s the right choice when your lighting layout needs more than two control points. The LED helps in low-light areas. The switch holds up well under daily use and carries the same refined aesthetic as the rest of the Unica X line.
